Beyma 6B30/P - 6.5" 50W 8 Ohm
This 6.5" unit has been designed to provide a wide, smooth response in the low and mid frequency range, with reduced harmonic distortion due the use of a copper ring on the pole piece, and polypropylene material in the cone construction for a clean, natural sound reproduction. This model is especially recommended for studio and domestic applications, in small size 2 or 3 way enclosure.
This is NOT a stock item, we can usually order this in and have stock within 40-44 working days. If you require this item urgently, please contact a member of staff to confirm availability.
TECHNICAL SPECIFICATIONS:
CONSTRUCTIVE DETAILS:
- Power capacity 50 W RMS
- Nominal diameter 165 mm 6.5 in
- Nominal impedance 8 ohm
- Minimum impedance 6.3 ohm
- Program power 80 W
- Sensitivity 90 dB 1 W @ 1m @ 2%u03A0
- Frequency range 55-8000 Hz
- Recommended enclosure volume -
- Voice coil diameter 25.4 mm 1 in
- BL factor 6.8 N/A
- Moving mass 0.014 kg
- Winding length 14 mm
- Air gap height 6 mm
- Xdamage pp 15 mm
Thiele and Small parameters: Need some help? Read our quick guide to TS Params.
- Fs 56 Hz
- Re 5.5 ohm
- Qms 3
- Qes 0.6
- Qts 0.50
- Vas 15.6 l
- Cms 564 μm / N
- Rms 1.67 kg/s
- Efficiency % 0.45
- Sd 0.014 sq m
- Xmax 5.5 mm
- Vd 77 cu cm
- Le @1 kHz 0.3 mH
CONSTRUCTIVE DETAILS:
- Net weight 1.25 kg 2.76 lb
- Total weight 1.5 kg 3.3 lb
- Magnet Ferrite
