B&C 15DS115 - 15" 1700W 8 Ohm Loudspeaker
Push Buttom Terminal

Product Code: BAC15DS115AM | Brand: B & C | Model: 15DS115
B&C 15DS115 - 15 inch 1700W 8 Ohm Loudspeaker

B&C 15DS115 - 15 inch 1700W 8 Ohm Loudspeaker B&C 15DS115 - 15 inch 1700W 8 Ohm Loudspeaker B&C 15DS115 - 15 inch 1700W 8 Ohm Loudspeaker
£454.90
£379.08 ex VAT
2-3 £441.25 ea.4-7 £432.15 ea.8+ £423.05 ea.
Login to see JAM Club pricing
Not a member? Join Now
Usually available in <br>3-4 weeks
Usually available in
3-4 weeks
FREE DELIVERY for mainland UK
B&C 15DS115 - 15" 1700W 8 Ohm Loudspeaker

  • 3400 W continuous program power capacity
  • 116 mm (4.5 in) four layer aluminium voice coil
  • 35 - 1000 Hz response
  • 97 dB sensitivity
  • Double silicone spider with optimized compliance
  • 60 mm peak-to-peak excursion before damage
  • Neodymium magnet allows a very high force factor and linear excursion
  • Ventilated voice coil gap for reduced power compression
  • Aluminium demodulating ring for very low distortion
Specifications:

  • Nominal Diameter 380 mm (15.0 in)
  • Nominal Impedance 8 Ohms
  • Minimum Impedance 7.2 Ohms
  • Nominal Power Handling 1700 W
  • Continuous Power Handling 3400 W
  • Sensitivity 97.0 dB
  • Frequency Range 35 - 1000 Hz
  • Voice Coil Diameter 116 mm (4.5 in)
  • Winding Material Aluminium
  • Former Material Glass Fibre
  • Winding Depth 40.0 mm (1.57 in)
  • Magnetic Gap Depth 14.0 mm (0.55 in)
  • Flux Density 0.8 T


Parameters:

  • Resonance Frequency 33 Hz
  • Re 4.9 ohms
  • Qes 0.18
  • Qms 5.2
  • Qts 0.17
  • Vas 94.0 dm3 (3.32 ft3)
  • Sd 855.0 cm2 (132.53 in2)
  • η₀ 1.90%
  • Xmax 16.5 mm
  • Xvar 14.0 mm
  • Mms 254.0 g
  • Bl 38.7 Txm
  • Le 4.5 mH
  • EBP 183 Hz


Design:

  • Surround Shape Triple Roll
  • Cone Shape Radial
  • Magnet Material Neodymium Inside Slug
  • Spider Double Silicone
  • Pole Design T-Pole
  • Woofer Cone Treatment TWP Waterproof Both Sides
  • Recommended Enclosure 80.0 dm3 (2.83 ft3)
  • Recommended Tuning 40 Hz


Dimensional Date:

  • Overall Diameter 393 mm (15.47 in)
  • Bolt Circle Diameter 375 mm (14.76 in)
  • Baffle Cutout Diameter 354.0 mm (13.94 in)
  • Depth 199 mm (7.83 in)
  • Flange and Gasket Thickness 15 mm (0.59 in)
  • Air Volume Occupied by Driver 7.0 dm3 (0.25 ft3)
  • Net Weight 11.6 kg (25.57 lb)
  • Shipping Units 1
  • Shipping Weight 12.9 kg (28.44 lb)
  • Shipping Box 425x425x224 mm (16.73x16.73x8.82 in)
