Faital Pro 8RS350 8" 300W 8 Ohm Loudspeaker

The new 8RS350 is an exceptional 8-inch speaker, oart a new range of low frequency optimised woofers, designed with a simple one-box solution in mind, low resonant frequency allows these transducers to hit that bottom octave in a studio monitors, background music speakers, or home cinema systems.

With a focus on high-quality construction and advanced design, the Faital Pro 8RS350 produces clear sound with a rich, full-bodied tone. Its flexible half roll cone surround contributes to a low Fs of 42Hz, making the 8RS350 capable of impressive bass response that will bring your music to life.

Technical specifications


  • Nominal Diameter: 200 mm (8in)
  • Overall Diameter: 223.7/207.9 mm (8.81/8.18in)
  • Bolt Circle Diameter: 210 mm (8.27in)
  • Baffle Cutout Diameter: 183 mm (7.20in)
  • Overall Depth: 106.5 mm (4.19in)
  • Flange/Gasket Thickness: 16 mm (0.63in)
  • Impedance: 8 ohm
  • Minimum Impedance: 6.2 ohm
  • AES Power: 300 W
  • Program Power: 600 W
  • Sensitivity: 90 dB
  • Frequency Range: 50:6300 Hz
  • Voice Coil Diameter: 65 mm (2.56in)
  • Voice Coil Material: Al
  • Voice Coil Former: Glass Fiber
  • Voice Coil Depth: 17.4 mm (0.69in)
  • Magnetic Gap Depth: 8 mm (0.31in)
  • Surround Type: Half
  • Spider Profile: 1x constant height waves
  • Chassis Material: Aluminum
  • Magnet Material: Ferrite Ring
  • Demodulating Ring: Aluminum Ring
  • Flux Density: 1.2 T
  • Driver Displacement Volume: 1.04 L (0.037ft^3)


Thiele and small parameters


  • Resonance (Fs) - 42 Hz
  • DC Resistance (Re) - 5.3 Ohm
  • Electrical Q (Qes) - 0.31
  • Mechanical Q (Qms) - 6.9
  • Total Q (Qts) - 0.30
  • Compliance Equivalent Volume (Vas) - 23.7 L
  • Diaphragm Area (Sd) - 226 cm2
  • Maximum Linear Excursion (Xmax) - 7.37 mm
  • Maximum Mechanical Excursion (Xdamage) - 16.85 mm
  • Moving Mass - System (Mms) - 43.3 g
  • Force Factor (BL) - 13.9 Tm
  • Voice Coil Inductance (Le) - 0.6 mH
  • Moving Mass - Diaphragm (Mmd) - 39.5 g
  • Compliance (Cms) - 0.33 mm/N
  • Mechanical Resistance (Rms) - 1.7 Kg/s
  • Reference Efficiency (Eta Zero) - 0.54 %
  • Efficiency Bandwidth Product (EBP) - 134

Shipping Information


  • Net Weight: 4.1 kg (9.0lb)
  • Shipping Weight: 4.8 kg (10.6lb)
  • Shipping Box: 235 x 235 x 155 mm

Notes

1 - AES Power: 2 Hours Test According to AES 2-1984 Rev. 2003
2 - Maximum/Program power is defined as 3 dB greater than AES Power
3 - Xmax: Xmax= [(winding depth - magnetic gap depth)/2] + (magnetic gap depth/3)
4 - Xdamage: Maximum excursion before permanent damage
