Eminence Legend 1275 A 12" 75W 8 Ohm Guitar Loudspeaker Driver


Product Code: EMILEG1275A | Brand: Eminence | Model: LEGEND 1275
Eminence Legend 1275 A 12 inch 75W 8 Ohm Guitar Loudspeaker Driver

Eminence Legend 1275 A 12 inch 75W 8 Ohm Guitar Loudspeaker Driver Eminence Legend 1275 A 12 inch 75W 8 Ohm Guitar Loudspeaker Driver Eminence Legend 1275 A 12 inch 75W 8 Ohm Guitar Loudspeaker Driver Eminence Legend 1275 A 12 inch 75W 8 Ohm Guitar Loudspeaker Driver
£125.09
£104.24 ex VAT
2-3 £123.21 ea.4-7 £121.34 ea.8+ £118.83 ea.
Login to see JAM Club pricing
Not a member? Join Now
Non Stock Item - Ordered on request
Ordered on Request
(21-25 days)
FREE DELIVERY for mainland UK
Eminence Legend 1275 A 12" 75W 8 Ohm Guitar Loudspeaker Driver

As the name suggests, the Legend Series offers classic tones from the past that have been utilised and made popular by many Eminence OEM amplifier customers since 1966. Featuring a British cone, 1.5" voice coil and 34 oz. ceramic magnet, the Legend 1275 offers tight, punchy lows, warm mids, and crisp, articulate, open highs.

"Often times we're asked what speaker from our line is equivalent to a custom OEM design in this amp, or that amp," says Anthony Lucas, Eminence Technical Support specialist. "With the Legend 1275, we wanted to offer something that combined the best tonal qualities from several of these most highly sought-after amp tones."


This is NOT a stock item, we can usually order this in and have stock within 21-25 working days. If you require this item urgently, please contact a member of staff to confirm availability.
SPECIFICATION:

  • Nominal Basket Diameter 12", 305mm
  • Nominal Impedance* 8 ohms
  • Power Rating: Watts (AES) 75W Music Program N/A
  • Resonance 111Hz
  • Usable Frequency Range 80Hz - 5.1kHz
  • Sensitivity 101.1dB
  • Magnet Weight 34 oz.
  • Gap Height 8mm
  • Voice Coil Diameter 38mm


THIELE & SMALL PARAMETERS:

  • Resonant Frequency (fs) 111Hz
  • DC Resistance (Re) 7.36
  • Coil Inductance (Le) 0.55mH
  • Mechanical Q (Qms) 15.07
  • Electromagnetic Q (Qes) 1.09
  • Total Q (Qts) 1.02
  • Compliance Equivalent Volume (Vas) 29.61 litres / 1.05 cu.ft.
  • Peak Diaphragm Displacement Volume (Vd) 25.9cc
  • Mechanical Compliance of Suspension (Cms) 0.07mm/N
  • BL Product (BL) 11.95 T-M
  • Diaphragm Mass Inc. Airload (MMs) 30 grams
  • Efficiency Bandwidth Product (EBP) 101
  • Maximum Linear Excursion (Xmax) 0.47mm
  • Surface Area of Cone (Sd) 552 cm2
  • Maximum Mechanical Limit (Xlim) N/A


MOUNTING INFORMATION:

  • Recommended Enclosure Volume: Sealed Acceptable Vented N/a
  • Driver Volume Displaced 1.93 litres
  • Overall Diameter 311.4mm
  • Baffle Hole Diameter 280.9mm
  • Front Sealing Gasket Yes
  • Rear Sealing Gasket Yes
  • Mounting Holes Diameter 6.4mm
  • Mounting Holes B.C.D. 297.4mm
  • Depth 112.8mm
  • Net Weight 3.18 kg
  • Shipping Weight 4.08 kgs


MATERIALS OF CONSTRUCTION:

  • Coil Construction Copper voice coil
  • Coil Former Polyimide former
  • Magnet Composition Ferrite Magnet
  • Core Details Non-vented core
  • Basket Materials Pressed steel basket
  • Cone Composition Paper cone
  • Cone Edge Composition Paper cone edge
  • Dust Cap Composition Zurette dust cap
