Eminence
Eminence LAB12 C - 12" 500W 4 Ohm
SPL: 88.9 1W/1m Fs: 23 Hz Xmax: 13.0mm

Product Code: EMILAB12C | Brand: Eminence | Model: LAB12 C
Eminence LAB12 C - 12 inch 500W 4 Ohm

Eminence LAB12 C - 12 inch 500W 4 Ohm Eminence LAB12 C - 12 inch 500W 4 Ohm Eminence LAB12 C - 12 inch 500W 4 Ohm Eminence LAB12 C - 12 inch 500W 4 Ohm
£213.58
£177.98 ex VAT
2-3 £210.37 ea.4-7 £207.17 ea.8+ £202.90 ea.
Login to see JAM Club pricing
Not a member? Join Now
FREE DELIVERY for mainland UK
Eminence LAB12 C - 12" 500W 4 Ohm

Compact driver with exceptional excursion for bass frequency reproduction. Recommended for vented, sealed and horn loaded, professional audio enclosures as a subwoofer. Often used for car or home cinema subs.

SPECIFICATION:

  • Nominal Basket Diameter 12", 304.8mm
  • Nominal Impedance 4 ohms
  • Power Rating Watts (AES) 500W
  • Music Program 1000W
  • Resonance 22.85Hz
  • Usable Frequency Range 25Hz - 0.12kHz
  • Sensitivity 88.9dB
  • Magnet Weight 160 oz.
  • Gap Height 0.37", 9.53mm
  • Voice Coil Diameter 2.5", 63.5mm


THIELE & SMALL PARAMETERS:

  • Resonant Frequency (fs) 22.85Hz
  • DC Resistance (Re) 3.11
  • Coil Inductance (Le) 1.09mH
  • Mechanical Q (Qms) 11.7
  • Electromagnetic Q (Qes) 0.34
  • Total Q (Qts) 0.33
  • Compliance Equivalent Volume (Vas) 128.31 liters / 4.53 cu.ft.
  • Peak Diaphragm Displacement Volume (Vd) 659cc
  • Mechanical Compliance of Suspension (Cms) 0.36mm/N
  • BL Product (BL) 13.36 T-M
  • Diaphragm Mass Inc. Airload (MMs) 135.63 grams
  • Efficiency Bandwidth Product (EBP) 67.29
  • Maximum Linear Excursion (Xmax) 13mm
  • Surface Area of Cone (Sd) 506.7 cm2
  • Maximum Mechanical Limit (Xlim) 22mm


MOUNTING INFORMATION:

  • Recommended Enclosure Volume Sealed 28.32-118.9 liters / 1-4.2 cu.ft. Vented 39.64-141.5 liters / 1.4-5 cu.ft.
  • Driver Volume Displaced 188.6 cu.in. / 3.09 liters
  • Overall Diameter 12.32", 312.93mm
  • Baffle Hole Diameter 10.98", 278.9mm
  • Front Sealing Gasket Fitted as standard
  • Rear Sealing Gasket N/A
  • Mounting Holes Diameter 0.26", 6.6mm
  • Mounting Holes B.C.D. 11.77", 299mm
  • Depth 6.44", 164mm
  • Net Weight 22 lbs, 10 kg
  • Shipping Weight 23.8 lbs, 10.8 kgs


MATERIALS OF CONSTRUCTION:

  • Coil Construction Copper voice coil
  • Coil Former Polyimide former
  • Magnet Composition Double stacked 80 oz. ferrite magnets
  • Core Details Vented and extended core
  • Basket Materials 12-spoke die-cast aluminium basket
  • Cone Composition Kevlar-reinforced paper cone
  • Cone Edge Composition Foam cone edge
  • Dust Cap Composition Dual inverted dust caps
