Technical specifications
- Nominal Diameter: 165 mm (6.5 in)
- Overall Diameter: 162 mm
- Bolt Circle Diameter: 170 mm
- Baffle Cutout Diameter: 145 mm
- Overall Depth: 81 mm
- Flange/Gasket Thickness: 9 mm
- Impedance: 8 ohm
- Program Power: 300 W
- Power: 150 W
- Sensitivity: 97 dB
- Frequency Range: 150-4500 Hz
- Voice Coil Diameter: 38 mm (1.5 in)
- Voice Coil Material: Copper
- Voice Coil Former: Kapton
- Voice Coil Depth: 9 mm
- Magnetic Gap Depth: 6 mm
- Cone Shape: Exponential
- Cone Material: Treated Cellulose Fibres
- Surround Type: Nomex
- Surround Material: Cotone
- Chassis Material: Aluminium
- Magnet Material: Neodimio
- Recommended Enclosure: Sealed Box
- Mounting Holes: 4
Thiele and Small parameters: Need some help? Read our quick guide to TS Params.
- Efficiency Bandwidth Product (EBP) - 278
- Resonance (Fs) - 150 Hz
- DC Resistance (Re) - 4.8 Ohm
- Mechanical Q (Qms) - 3
- Electrical Q (Qes) - 0.54
- Total Q (Qts) - 0.46
- Force Factor (BL) - 10.5 Tm
- Moving Mass - Diaphragm (Mmd) - 13.2 g
- Cas (Cas) - 2.5
- Dd (Dd) - 137
- Diaphragm Area (Sd) - 147 cm2
- Maximum Linear Excursion (Xmax) - 3 mm
- Voice Coil Inductance (Le) - 1 mH
- Reference Efficiency (Eta Zero) - 1.5 %
Shipping Information
- Net Weight: 1.35 kg
- Multipack Quantity: 6
